GC-DXC1 Series 20A Electric Vehicle Plastic HVIL Connector

GC-DXC1 Series HVIL connectors are a series of high voltage connectors capable of handling up to 20A at 1000V DC. The GC-DXC1 Series 20A high voltage cable connectors are designed for use in the automotive industry. They are designed to withstand extreme temperatures ranging from -40°C to +140°C. They also have a waterproof rating of IP67, which means they are resistant to dust and moisture. The connector is easy to install and has a high reliability. It is made of high quality materials and has excellent durability.
Temp Range :
-40℃~ +140℃
Rated current :
20A
Rated Voltage :
1000V
Sealing Class :
IP68 IP69K
Share:
Guchen 20A EV High Voltage Interlock Connectors Details
The GC-DXC1 Series is a 20A low current high voltage connector with Terminal Position Assurance (TPA) Function.
It is designed for electric vehicles to make the connection between the wire and the cable end of the vehicle's electric system. The EV connector has different sizes for use with different wire section diameters. Anti-corrosion materials make the connector reliable in severe environments.
High Voltage Interlock Loop connector
Features of GC-DXC1 Series 20A HV Interlock Plastic Connectors
◆ High Voltage Interlock Loop connector
It implements a high voltage interlock loop (HVIL) design which provides an additional layer of protection against overvoltage in case of short circuits or other abnormal conditions that may lead to an electrical accident during vehicle operation.

◆ Plug and Receptacle with Terminal Position Assurance (TPA) Function,

The GC-DXC1 Series 20A EV Connectors are designed with a plug and receptacle with TPA function. With this function, it can be used in all kinds of environments without any worry about the risk of electric shock caused by improper installation or wrong polarity connection. The unique design of TPA makes it easy for users to connect and disconnect terminals, ensuring stable operation of the vehicle battery system.

◆ Two Stage Latching

The two stage latching/locking prevents accidental disconnection of the high voltage circuit. The latching system of this 20A low current HVIL connector can effectively prevent the disconnection of the plug and receptacle caused by vibration or impact during vehicle operation.

◆ Plastic shell

The shell is made of plastic, which makes it lightweight & durable, and ensures the safety and reliability of use.

◆ Widely wire section options
Cable cross section: 2x2.5mm², 2x4mm², 2x6mm²

◆ IP68 waterproof standard
Applications
GC-DXC1 Series Plastic HVIL Connector has been designed to be used for high voltage DC power transmission requiring low currents. It is designed for the high voltage connection of on-board charger, battery pack, PDU, motor controller, AC, PTC and DC/DC etc.
20A low current HVIL connector
20A High Voltage Interlock Connector
Guchen 20A High Voltage Interlock Connector
20A HVIL Connector Plug and Receptacle
GC-DXC1-20A HVIL Connector, Plug and Receptacle
20A Plastic Connector with High Voltage Interlock Loop
Application of 20A Plastic Connector with High Voltage Interlock Loop
Electric Bus HVIL Connector
Electric Bus HVIL Connector
Configurations

Description Item No. GC-DXC1-20A
Electrical Performance Rated voltage 1000V
Withstand voltage 4000V
Rated current 20A
Insulation resistance 5000MΩ
Mechanical Properties Pins 2pins
Mating cycles >100 Times
Cross sections 2x2.5mm²
Vibration class acc. To QC/T 1067.1-2017 V2
Raw Material Shell PA66
Shielding Copper alloy
Insulator PA66
Sealing Rubber material
Environmental Performance Operating temperature -40℃~140℃
Protection Grade IP68 IP6K9K
Salt Spray 504h
