EV HV Connectors
Electric vehicle connectors supplied by Guchen Electronics are with excellent shielding, fast safe easy assembling, wide wire section options, compact design and multi positions connectors options. In order to meet different requirements, we provide our customers with various types of quality HV connectors, widely used in the fields of automotive electronics.
-
Rated voltage : 1500V
Withstand voltage : 4000VAC/6000VDC;
Rated current : 200A max.
Cross sections : 16/25/35/50mm2
Water proof : IP68 & IP6K9K
Pole : 1 PinGCMC1 1-Pin 200A 1500V High Voltage Connector -
Rated voltage : 1000V
Withstand voltage : 3000V AC
Rated current : 100A; 120A
Cross sections : 16mm²; 25mm²
Water proof : IP67
Pole : 2 PosGC-EVH600 2 Poles Metal Connector for 16mm2 & 25mm2 Cable -
Rated voltage : 1000V
Withstand voltage : 4000V AC
Rated current : 20A; 32A; 40A
Cross sections : 2.5mm²; 4mm²; 6mm²
Angle : 90° bent, 180°
Pole : 4 PosGC-DXC1 4 Pole Automotive Electrical HVIL Connector -
Hole: 1
Rated voltage : 1000V
Cross section: 120mm² shielded
Rated current : 350A
Operating temperature : -40℃~125℃
IP Grade: IP68, IP6K9KFPT112 1-Hole 350A Pass-through Metal Connector for 120mm² Shielded Cables
EV HV Wiring Harness
Guchen Electronics is a professional manufacturer of HV assembled wiring harnesses for electric passenger cars and commercial vehicles. We always pay attention to the quality of HV cables & connectors, and provide global EV manufacturers with high quality products and excellent service.
-
Withstand Voltage: up to 1500V
Current: 20A-300A
Color: Yellow
Material: XLPE material
Temperature range: -40℃~180℃
Custom design: YESBAT High Voltage Wire Harness -
Withstand Voltage: 1500V
Current: 20A-300A
Material: XLPE material
Temperature range: -40℃~180℃
Custom design: YESMCU High Voltage Wire Harness Assembly -
Withstand Voltage: 1500V
Current: 20A-300A
Material: XLPE material
Temperature range: -40℃~180℃
Custom design: YESPTC&AC High Voltage Wire Harness -
Withstand Voltage: 1500V
Current: 20A-300A
Material: XLPE material
Temperature range: -40℃~180℃
Custom design: YESDC-DC High Voltage Wire Harness
EV HV Cable
We have a wide range of high voltage cables for passenger car and commercial vehicles like bus, truck, coach etc. Guchen EV HV cables can handle high currents and high voltage. They are high temperature resistant, soft, and with variable options (2.5mm²~120mm² sizes, shielded or unshielded, copper or aluminum cable options). Guchen cables are full customizable to meet different EV requirements.
-
Rated Temp.: -40℃~125℃/150℃
Insulation: XLPE/XLPO
Rated Voltage: DC900V/1500V
Conductor: Aluminum Alloy
Wire Diameter: 2.5mm²~120mm²Shielded High Voltage XLPO/XLPE-Insulated Aluminum Cable -
Rated Temp.: -40℃~175/200℃
Insulation: Silicone rubber
Rated Voltage: DC900V/1500V
Conductor: Copper
Wire Diameter: 2.5~120mm²Shielded High Voltage Silicone Rubber Copper Cable -
Rated Temp.: -40℃~125℃
Insulation: XLPE/XLPO
Rated Voltage: DC900V/1500V
Conductor: Copper
Wire Diameter: 2.5mm²~120mm²Shielded High Voltage XLPE/XLPO Multi-Core Copper Cable -
Rated Temp.: -40℃~125℃/150℃
Insulation: XLPE/XLPO
Rated Voltage: DC900V/1500V
Conductor: Copper
Wire Diameter: 2.5mm²~120mm²Shielded High Voltage XLPE/XLPO Single-Core Copper Cable
EV Charging Equipment
Our range of portable EV chargers and charging cables provide convenient charging solutions for electric vehicle owners. To enable charging from public stations, we offer a selection of premium type 2 to type 2 (type 1) EV charging cables in various lengths (5m, 7m, 10m etc.). these thick, flexible charging cables are made with top-quality components to provide reliable charging session after session. The charging connectors lock securely into your vehicle’s inlet and the station to provide a safe and consistent charge.
-
Power: 7.2KW
Rated current: 32A
Operation voltage: 250V
Operating temperature: -30℃~50℃
Withstand voltage: 2000V7.2Kw 32A 1 Phase Type 2 to Type 2 EV Charging Cable -
Power : 11KW
Rated current : 16A
Operation voltage : 480V
Operating temperature : -30℃~50℃
Withstand voltage : 2000V11Kw 16A 3 Phase Type 2 to Type 2 EV Charger -
Power: 3.6KW/7.2kw
Rated current: 16A 1PH
32A 1PH
Operation voltage: 250V
Temperature: -30℃~50℃Mode 3 EV Charging Cable | Type 1 to Type 2 | 3.6KW 16A | 7.2KW 32A -
Power : 22KW
Rated current : 32A
Operation voltage : 480V
Operating temperature : -30℃~50℃
Withstand voltage : 2000V22Kw 32A 3 Phase Type 2 to Type 2 EV Charging Cable
EV Charging Connectors (Socket & Plug)
We can offer premium quality type 2 charging gun, CCS2 DC charging plug, CCS2 charging socket vehicle inlet etc. Guchen EV Charging Connectors are built with precision and reliability in mind. All of our EV charging plugs and sockets are made from high-quality materials engineered to withstand daily use in public charging stations. We've rigorously tested them to meet the latest standards for safety, charging speed and reliability. Guchen Electronic aims to be a leading supplier of charging solutions as electric vehicles become more prevalent worldwide. Please contact us to learn more about our EV charging connectors.
-
Rated voltage : 1000V DC
Rated current : Max 300A
Mating cycles : >10000 times
Ambient temperature : -40℃~+50℃
Protection Grade: IP44, IP24
Temp. rise: <50KCCS2 DC EV Charging Plug/Gun -
Rated voltage : 1000V
Resistant voltage : 3000V AC/1 min
Rated current : Max 500A
Mating cycles : >10000 times
Ambient temperature : -30℃~50℃
Protection Grade: IP55 IP44CCS2 EV DC Charging Socket (Vehicle Inlet)
Energy Storage Connector
Guchen Electronics is specialized in designing and manufacturing of electric vehicle high voltage connectors (with various specifications and features), HV wire harness & cables, EV charging equipment, and HV connectors for Battery Energy Storage System (BESS).
-
Model : GCS1 6mm
Conductor cross-section : 16mm², 25mm²
Rated current : 100A, 120A
Rated voltage : 600V
Insulation resistance : 5000MΩGCS1 6mm 100A-120A Battery Pole Connector -
Model : GCS1 8mm
Conductor cross-section : 25mm², 35mm², 50mm²
Rated current : 120A, 150A, 200A
Rated voltage : 1500V
Insulation resistance : 5000MΩ
Operating temperature : -40℃~125℃GCS1 8mm 120A-200A Energy Storage Connector -
Model : GCS1 12mm
Conductor cross-section : 70mm², 95mm², 120mm²
Rated current : 250A, 300A, 350A
Rated voltage : 1500V
Insulation resistance : 5000MΩ
Operating temperature : -40℃~125℃GCS1 12mm 250A-350A Battery High Voltage Connector -
Model : GCS2
Rated current : 300A
Rated voltage : 1500V
Protection class : IP65
Operating temperature : -40℃~125℃GCS2 300A Battery Copper Bus Bar Connector
Li-ion Battery Fire Protection System
The most effective lithium-ion battery fire protection system is using nitrogen gas as protection to lower the oxygen level in the power battery box. By this method, If the battery box catches fire due to external factors, the nitrogen stored in the gas tank provides protection, isolates oxygen in the air, prevents thermal runaway, and prevents explosion.
